LP-A104 Series

The LP-A104 series logic panels are all-in-one devices featuring functions of PLC, HMI, and I/O modules with 32 input and 32 output contact points. The 10.4-inch widescreen TFT LCD display offers excellent visibility and data management capability. The resistive touchscreen (analog touch) allows flexible tag arrangements, and the data logger function allows data storing and backup from various control devices. The units can be installed horizontally or vertically, and also feature support for various connection interfaces including USB Host/Device, Ethernet, and CAN.

Compare
Categories: , ,

Description

  • All-in-one device including functions of PLC, HMI, and I/O modules
  • Horizontal/vertical installation
  • Various communication interface support: RS232C, RS422/485, Ethernet, CAN
  • 32 input and 32 output points provided
  • Device monitoring of connected device possible without screen data
  • Motion control and high-speed counting function included
  • 10.4-inch TFT LCD True Color display capable up to 16,777,216 color variations
  • Resistive touchscreen allows operation with bare hands, gloved fingers, or stylus

10.4-Inch Touchscreen

Space and Cost Saving

Vertical/Horizontal Setup

Resolution

Screen Editor Software

Logic Programming Software

  • All-In-One Touch Panel with PLC, HMI, and I/O Module Functions

    The all-in-one device features functions of PLC, HMI, and I/O modules offering easy space-saving installation with minimal wiring. Convenient total control is possible from a single access device.

    All-In-One Touch Panel
  • 32 Input and 32 Output Points

    Multiple I/O points are provided for simple system setup without requiring PLCs.

    32 Input and 32 Output Points
  • CAN Communication

    The LP-A104 series can be set as a Master device with CANopen communication protocol to connect multiple I/O devices. Autonics ARD series and ARIO (DeviceNet models) series I/O can be used as slave devices.

    CAN Communication
  • atLogic Logic Programming Software

    Users can create and edit ladder programs using the atLogic ladder programming software.

    Logic Programming Software
