Description
Main features
- Detection area : 90˚, 5.6 m x 5.6 m
- Supports up to 4 operation channels
- Compact size (W125 x H80.3 x L88 mm) for diverse applications
- Ethernet communication
- Dedicated software atLiDAR provided for PC
- Remote control (RMC-LS, sold separately)
Detection Area
4 Channel Laser Beam
Set Non-Detection Area
Remote Control
Dedicated Software
Protection Rating
90˚ Detection Angle, 5.6 m x 5.6 m Detection Area
The LSE series laser scanners offer 5.6 m x 5.6 m detection area with horizontal 90˚ detection angle.
4 Channel Laser Beam for Accurate Detection
4 separate laser beam channels are available, and each channel can detect up to 5.6 m x 5.6 m areas. Users can activate 1 to 4 channels individually or simultaneously, offering flexible and precise detection.
Set Concentrated Monitoring Area
Users can set the detection area and concentrated monitoring area and remove unnecessary fields from the detection area.
Unnecessary detection area: 10 to 30 cm (set by 10 cm)
Auto Set Detection Area with Teaching Function
Users can use the teaching function to automatically set optimal detection area. This function can be operated also with dedicated software and other input signals.
Dedicated Laser Scanner Software atLiDAR
Users can easily set parameters and monitor status of the scanners using the atLiDAR software with user-friendly interface.
Easy Parameter Settings Using Remote Control
Users can easily set parameters using a laser remote control.
