Description
General data
Approval | CE UL/cUL UKCA |
Technical data
Electrical data
Supply voltage (V) | 10 – 33 V |
Type of supply voltage U1 | DC |
Optical data
Used wavelength range |
Environmental data
Ambient temperature | -25 – 60 °C |
Perm. operating height ASL | 2000 m |
EMC to standard … | EN 60947-5-2 |
Vibration to standard … | EN 60068-2-6 |
Acc. shock to standard1 | 50g |
Protection type, housing |
Times
Reaction time | 0 – 2.4 ms |
Mechanical data
Connection type | M8, 4-pin male |
Housing material | Plastic |
Height dimension | 39.1 mm |
Width dimension | 12.9 mm |
Depth dimension | 23 mm |
Net weight | 8 g |
Gross weight | 23 g |
