Description
General data
| Approval | CE cULus Listed EAC (Eurasian) TÜV |
| ESPE type | 4 |
| Sensor principle | Infrared |
| Resolution protection type | Body |
| Operating range (m) | 0 – 8 m |
Technical data
Electrical data
| Supply voltage (V) | 20 – 30 V |
| Type of supply voltage U1 | DC |
Optical data
| Used wavelength range | 880 nm |
Semiconductor outputs
| Number of OSSD outputs | 0 |
Environmental data
| Ambient temperature | -25 – 55 °C |
| Climatic suitability standard | EN 60068-2-3 |
| Humidity rating | 95 % r. h. at 40 °C |
| Condensation permitted? | Not permitted |
| Vibration to standard … | EN 60068-2-6 |
| Acc. shock to standard1 | 30g |
| Protection type, housing |
Times
| Reaction time | 1 ms |
Mechanical data
| Connection type | M12 4-pin |
| Housing material upper part | ABS UL 94 V0 |
| Depth dimension | 62.6 mm |
| Net weight | 44 g |
| Gross weight | 73 g |
