PSS Series

The PSS series analog pressure sensors feature rectangular design with compact sizes (W 11.8 mm x H 29.3 mm x L 24.8 mm, including pressure port). The pressure sensors are available in analog voltage and analog current models and can be connected directly to HMIs, PCs, and PLCs from various brands. With a wide rated pressure range, the PSS series sensors can be applied in various pressure related applications.

Compare

Description

※ Reducer pressure port (Φ4, Φ6) models have been added to the line-up.

  • Rated pressure range
    – negative pressure (0kPa to -101.3kPa)
    – positive pressure (0kPa to 100.0kPa/0kPa to 1000kPa)
    – compound pressure (-101.3kPa to 100kPa)
  • Compact design :
    – [Standard model (R1/8 port)] W 11.8 mm x H 29.3 mm x L 24.8 mm (including pressure port)
    – [Optional Model (reducer port)] W 11.8 mm x H 31.3 ~ 32.8 mm x L 24.8 mm (including pressure port)
  • Analog output : voltage (1-5VDC), current (DC 4-20mA)
  • Power supply: 12-24 VDC ±10%

PRESSURE

Wide Pressure Range

Compact Size

1-5VDC, 4-20mA

Analog Output

Reverse Polarity Protection Circuit

Compact Sized Sensors for Installation in Limited Spaces

The rectangular type pressure sensors with compact size can be installed in limited spaces.

PSS-1
PSS-2

Easy Mounting with Reducer Port Type

One-touch mounting is available with reducer pressure port for convenient installation.

PSS-3
